PICTORIAL INDEX
WDS
WDS
www.wdsltd.co.ukIndex 34
&
0845 606 66 77
•
:
www.wdsltd.co.uk•
*
sales@wdsltd.co.uk WDS 450 Round Face Cone Side Guide PAGE 16-9 WDS 450 Conveyor Tube PAGE 16-10 WDS 778 Steel Nickel Plated, Plastic Base Levelling Foot PAGE 16-11 WDS 778 Steel Nickel Plated, Plastic Base Levelling Foot PAGE 16-11 WDS 778 Steel Nickel Plated, Plastic Base Levelling Foot PAGE 16-12 WDS 778 Extended Bolt Down Base Levelling Foot PAGE 16-12 WDS 778 Double Bolt Down Levelling Foot PAGE 16-13 WDS 778 Stainless Steel, Plastic Base Levelling Foot PAGE 16-13 WDS 778 Stainless Steel, Plastic Base Levelling Foot PAGE 16-14 WDS 778 Stainless Steel, Plastic Base Levelling Foot PAGE 16-14 WDS 778 Stainless Steel, Extended Bolt Down Base Levelling Foot PAGE 16-15 WDS 778 Stainless Steel, Double Bolt Down Levelling Foot PAGE 16-15 WDS 566 Ball Transfer Unit - Surface Mounting 2 Hole Fitting PAGE 16-16 WDS 566 Ball Transfer Unit - Surface Mounting 4 Hole Fitting PAGE 16-16 WDS 567 Ball Transfer Unit - Surface Mounting 2 Hole Fitting PAGE 16-16 WDS 570 Ball Transfer Unit - High Capacity (Spring Loaded External) PAGE 16-17 WDS 570 Ball Transfer Unit High Capacity - push Fit Series PAGE 16-18 WDS 568 Ball Transfer Unit, Stem Fitting PAGE 16-18 WDS 570 Ball Transfer Unit High Capacity - Hex Threaded Stud Series PAGE 16-19 WDS 570 Ball Transfer Unit - High Capacity Based Mounted PAGE 16-19 WDS 570 Ball Transfer Unit - High Capacity Top Mounted PAGE 16-20 WDS 570 Ball Transfer Unit - High Capacity (Spring Loaded Internal) PAGE 16-20 WDS 569 Ball Transfer Unit - Light Duty, with Clip PAGE 16-21 WDS 570 Ball Transfer Unit - Medium Duty PAGE 16-21 WDS 570 Ball Transfer Unit - Medium Duty with Rubber PAGE 16-22 WDS 689 Plastic Insert for Square Tube PAGE 17-1 WDS 690 Plastic Insert for Round Tube PAGE 17-2 WDS 12186 Square Tube - Type S PAGE 17-3 WDS 12186 Round Tube - Type R PAGE 17-3 WDS 688 Round 304 Stainless Steel Threaded Weld Plates PAGE 17-4SECTION16
SECTION17
