SECTION 2 - LOCATION & POSITIONING
WDS
WDS
www.wdsltd.co.uk2-57
&
0845 606 66 77
•
:
www.wdsltd.co.uk•
*
sales@wdsltd.co.ukThreaded Split
Shaft Collars -
Coarse Pitch
WDS 650
MATERIAL
-
Steel, Black Oxide Finish.
D
D1
B (JS14)
D2
(g)
WDS No.
M6 x 1.0
16
9
M3 x 8
12
650-306C
M8 x 1.25
18
9
M3 x 8
15
650-308C
M10 x 1.5
24
9
M3 x 8
27
650-310C
M12 x 1.75
28
11
M4 x 10
44
650-312C
M16 x 2.0
34
13
M5 X 12
73
650-316C
M20 x 2.5
40
15
M5 X 12
112
650-320C
D1
D2
B
D
Threaded Split
Shaft Collars -
Fine Pitch
WDS 650
MATERIAL
-
Steel, Black Oxide Finish.
D
D1
B (JS14)
D2
(g)
WDS No.
M8 x 1.0
18
9
M3 x 8
15
650-308F
M10 x 1.0
24
9
M3 x 8
27
650-310F
M12 x 1.5
28
11
M4 x 10
44
650-312F
M16 x 1.5
34
13
M5 x 12
73
650-316F
M20 x 1.5
40
15
M5 X 12
112
650-320F
D1
D2
B
D
