SECTION 3 - HAND LEVERS
WDS
&
0845 606 66 77
•
:
www.wdsltd.co.uk•
*
sales@wdsltd.co.uk3-8
WDS
www.wdsltd.co.ukSwivel Pad
Swivel Pad
WDS 821/8921
WDS 821/8921
MATERIAL
-
Stainless Steel
BS 970 Gr 316S11 / 303S31
See 671 Series for this part in Steel
MATERIAL
-
Stainless Steel
BS 970 Gr 316S11 / 303S31
See 671 Series for this part in Steel
D
D1
D2
L
(g)
WDS No.
Material 316S11
WDS No.
Material 303S31
M6
10
5
8
4
821-4002
8921-4002
M8
12
6
9
8
821-4006
8921-4006
M10 or M12
14
8
11
10
821-401
8921-401
D
D1
D2
D3
L
E
(g)
WDS No.
Material 316S11
WDS No.
Material 303S31
M8
18
12
12
9
4
11 821-4008
8921-4008
M10 or M12 22
16
14
11
5
19 821-402
8921-402
M10 or M12 28
22
14
11
6
33 821-404
8921-404
M10 or M12 35
29
14
11
6
45 821-406
8921-406
'
'
/
(
'
'
'
/
Note: WDS 8921 has 5mm diameter dimple instead of
D2 counter bore.
Note: WDS 8921 has 5mm diameter dimple instead of
D2 counter bore.
316 303
316 303
D=screw size - refer to 820 and 822 Series
D=screw size - refer to 820 and 822 Series
