Cam Lever
WDS 368
MATERIAL
-
Handle - Cast Aluminium
EN: AC-46200 - Black powder
coated
Thrust washer - GRP PA66 GF35
Black
Stud, Hinge Pin, and Washer-
Stainless Steel 1.4305
D D1 D2 A A1 B B1 H H1 L Stroke
Hand
Force (N)
Clamping
Force (kN)
(g)
WDS No.
M3 12 6 36 42 14 11.5 9 13 10
1
90
1.5
26 368-60310
M3 12 6 36 42 14 11.5 9 13 15
1
90
1.5
29 368-60315
M3 12 6 36 42 14 11.5 9 13 30
1
90
1.5
31 368-60330
M4 12 6 36 42 14 11.5 9 13 10
1
90
1.5
28 368-60410
M4 12 6 36 42 14 11.5 9 13 15
1
90
1.5
32 368-60415
M4 12 6 36 42 14 11.5 9 13 20
1
90
1.5
12.5 368-60430
M4 15.5 8 52 59 18 13 11 17 15
1
100
2.5
23.8 368-61415
M4 15.5 8 52 59 18 13 11 17 20
1
100
2.5
25 368-61420
M4 15.5 8 52 59 18 13 11 17 30
1
100
2.5
31.5 368-61430
M5 15.5 8 52 59 18 13 11 17 20 1.2
100
2.5
25.2 368-60520
M5 15.5 8 52 59 18 13 11 17 30 1.2
100
2.5
23.9 368-60530
M5 15.5 8 52 59 18 13 11 17 40 1.2
100
2.5
34.1 368-60540
M5 15.5 8 52 59 18 13 11 17 50 1.2
100
2.5
40 368-60550
M5 18 9 70 79 22 15 14.5 22 20 1.2
120
4
38.9 368-61520
M5 18 9 70 79 22 15 14.5 22 30 1.2
120
4
39.5 368-61530
M5 18 9 70 79 22 15 14.5 22 40 1.2
120
4
40.2 368-61540
M5 18 9 70 79 22 15 14.5 22 50 1.2
120
4
40.9 368-61550
M6 18 9 70 79 22 15 14.5 22 20 1.2
120
4
40.1 368-60620
M6 18 9 70 79 22 15 14.5 22 30 1.2
120
4
40.8 368-60630
M6 18 9 70 79 22 15 14.5 22 40 1.2
120
4
41.5 368-60640
M6 18 9 70 79 22 15 14.5 22 50 1.2
120
4
42.2 368-60650
M8 18 9 96 108 33 24 18 28.5 25 1.5
350
8
114.8 368-60825
M8 18 9 96 108 33 24 18 28.5 30 1.5
350
8
115.4 368-60830
M8 18 9 96 108 33 24 18 28.5 40 1.5
350
8
117.7 368-60840
M8 18 9 96 108 33 24 18 28.5 50 1.5
350
8
119.9 368-60850
M10 27 11 96 108 33 24 18 28.5 25 1.5
350
8
120.8 368-61025
M10 27 11 96 108 33 24 18 28.5 30 1.5
350
8
127.7 368-61030
M10 27 11 96 108 33 24 18 28.5 40 1.5
350
8
130.2 368-61040
M10 27 11 96 108 33 24 18 28.5 50 1.5
350
8
132.7 368-61050
'
'
+
'
/
+
