SECTION 3 - HAND LEVERS
WDS
WDS
www.wdsltd.co.uk3-13
&
0845 606 66 77
•
:
www.wdsltd.co.uk•
*
sales@wdsltd.co.ukAluminium/Steel
Cam Lever
WDS 369
MATERIAL
-
Handle - Cast Aluminium
EN: AC-46200 - Black powder
coated
Thrust washer - GRP PA66 GF35
Black
Internal Thread, stud & washer -
Steel Class 5.8
D D1 D2 A A1 B B1 H H1 Stroke
Hand Force
(N)
Clamping
Force (kN)
(g)
WDS No.
M3 12 6 36 42 14 11.5 9 13
1
90
1.5
14.9
369-203
M4 12 6 36 42 14 11.5 9 13
1
90
1.5
10.5
369-204
M4 15.5 8 52 59 18 13 11.2 17
1
100
2.5
16.7
369-214
M5 15.5 8 52 59 18 13 11.2 17
1
100
2.5
17.7
369-205
M5 18 9 70 79 22 15 14.5 22
1.2
120
4.0
34.1
369-215
M6 18 9 70 79 22 15 14.5 22
1.2
120
4.0
32.9
369-206
M8 27 11 96 108 33 24 18 28.5 1.5
350
8.0
98.9
369-208
D1
H
D2
H1
D
Hand
Force
Clamp
Force
A
B1
B
A1
Aluminium/
Stainless Steel
Cam Lever
WDS 369
MATERIAL
-
Handle - Cast Aluminium
EN: AC-46200 - Black powder
coated
Thrust washer - GRP PA66 GF35
Black
Internal Thread, stud & washer -
Stainless Steel 1.4305
D D1 D2 A A1 B B1 H H1 Stroke
Hand Force
(N)
Clamping
Force (kN)
(g)
WDS No.
M3 12 6 36 42 14 11.5 9 13
1
90
1.5
16
369-603
M4 12 6 36 42 14 11.5 9 13
1
90
1.5
12
369-604
M4 15.5 8 52 59 18 13 11.2 17
1
100
2.5
17.9
369-614
M5 15.5 8 52 59 18 13 11.2 17
1
100
2.5
18
369-605
M5 18 9 70 79 22 15 14.5 22
1.2
120
4.0
34.1
369-615
M6 18 9 70 79 22 15 14.5 22
1.2
120
4.0
32.9
369-606
M8 27 11 96 108 33 24 18 28.5 1.5
350
8.0
98.9
369-608
D1
H
D2
H1
D
Hand
Force
Clamp
Force
A
B1
B
A1
