sales@wdsltd.co.ukClamping Lever -
Indexing
WDS 8238
MATERIAL
-
Handle - Plastic PA6
Thread- Steel Zinc plated
D
D1
D2
H
H1
L
L1
WDS No.
M5
15
11.5
33
4
45
15
8238-20515
M5
15
11.5
33
4
45
20
8238-20520
M5
15
11.5
33
4
45
25
8238-20525
M6
15
11.5
33
4
45
15
8238-20615
M6
15
11.5
33
4
45
20
8238-20620
M6
15
11.5
33
4
45
30
8238-20630
M8
20
16
43
7
65
20
8238-20820
M8
20
16
43
7
65
30
8238-20830
M8
20
16
43
7
65
50
8238-20850
M10
22.5
19
54
12
80
25
8238-21025
M10
22.5
19
54
12
80
40
8238-21040
M10
22.5
19
54
12
80
50
8238-21050
M12
27
21.5
63
13
95
25
8238-21225
M12
27
21.5
63
13
95
40
8238-21240
M12
27
21.5
63
13
95
60
8238-21260
