SECTION 3 - HAND LEVERS
WDS
WDS
www.wdsltd.co.uk3-29
&
0845 606 66 77
•
:
www.wdsltd.co.uk•
*
sales@wdsltd.co.ukB
D1
D
D2
L
T
H1
H
20°
%
'
'
/
+
+
7
'
r
Clamping Lever
WDS 8162
MATERIAL
-
Handle - Glass fibre reinforced
plastic, black
Insert - Steel, zinc plated
Clamping Lever
WDS 8162
MATERIAL
-
Handle - Glass fibre reinforced
plastic, black
Screw - Steel, zinc plated
D
B
D1
D2
H
H1
L
T
(g) WDS No.
M5
8
14
13.8
27
11
40
11
9 8162-212
M6
8
14
13.8
27
11
40
11
7 8162-213
M8
9
18.5
18.3
37
11
65
12
19 8162-214
M10
11
22
21.8
45
14
80
16
22 8162-215
M12
13
26
25.8
54
17
95
20
45 8162-216
M16
16
31
30.8
63
21
110
24
53 8162-217
D
B
D1
D2
H
H1
L
T
(g)
WDS No.
M5
8
14
13.8
27
11
40
11
11 8162-222
M6
8
14
13.8
27
11
40
11
12 8162-223
M8
9
18.5
18.3
37
11
65
12
29 8162-224
M10
11
22
21.8
45
14
80
16
43 8162-225
M12
13
26
25.8
54
17
95
20
79 8162-226
M16
16
31
30.8
63
21
110
24
132 8162-227
The WDS 8162 series is non-
indexable. Refer to the WDS 8188
& 8189 series for indexable and
parking type.
