SECTION 4 - HANDWHEELS & GRIPS
WDS
WDS
www.wdsltd.co.uk4-7
&
0845 606 66 77
•
:
www.wdsltd.co.uk•
*
sales@wdsltd.co.ukAluminium
Handwheel with
Turned Rim -
Keywayed Bore
Tapped for Grip
WDS 8179
MATERIAL
-
Aluminium AlSi9Mg, Boss Machined,
Rim Turned
Tapped for grip
N = No of Spokes
D
E
A
F
M
D2
L1
L
B
D1
+0.2
Al
D
B D1(H7)
D2
L
L1
A E (Js9)
F
M N
(g)
WDS No.
80
14
10
24
29
16
27
3
11.4
M6
3
120
8179-450
100
15
10
26
33
17
36
3
11.4
M6
3
180
8179-451
125
16
12
28
36
18
47
4
13.8
M8
3
255
8179-452
160
18
14
32
40
20
62
5
16.3
M10
3
412
8179-453
200
22
18
38
45
24
80
6
20.8
M10
3
756
8179-454
250
26
22
45
50
28
101
6
24.8
M12
5
1420
8179-455
315
26
26
53
56
33
132
8
29.3
M12
5
2250
8179-456
400
32
30
65
63
38
171
8
33.3
M16
5
3810
8179-457
500
34
34
78
72
45
220
10
37.3
M16
5
5690
8179-458
Aluminium
Handwheel with
Turned Rim -
Keywayed Bore
with Fixed Grip
WDS 8179
MATERIAL
-
Aluminium AlSi9Mg, Boss machined,
Rim Turned
Fixed aluminium polished grip
supplied loose
D B D1(H7)
D2 L
L1 A E(Js9)
F
H J
M N
(g)
WDS No.
80
14
10
24
29
16
27
3
11.4
55
16
M6
3
203 8179-450AF
100
15
10
26
33
17
36
3
11.4
55
16
M6
3
203 8179-451AF
125
16
12
28
36
18
47
4
13.8
70
20
M8
3
302 8179-452AF
160
18
14
32
40
20
62
5
16.3
85
25
M10
3
502 8179-453AF
200
22
18
38
45
24
80
6
20.8
85
25
M10
3
846 8179-454AF
250
26
22
45
50
28
101
6
24.8 100
32
M12
5
1575 8179-455AF
315
26
26
53 56
33
132
8
29.3 100
32
M12
5
2406 8179-456AF
400
32
30
65
63
38
171
8
33.3 111
36
M16
5
4036 8179-457AF
500
34
34
78
72
45
220
10
37.3 111
36
M16
5
5916 8179-458AF
N = No of Spokes
D
E
A
F
D2
L1
L
B
D1
H
J
M
+0.2
Al
