SECTION 5 - HAND KNOBS
WDS
&
0845 606 66 77
•
:
www.wdsltd.co.uk•
*
sales@wdsltd.co.uk5-90
WDS
www.wdsltd.co.ukFive Lobe Knob -
Threaded Through
Hole
WDS 8199
MATERIAL
-
Bakelite, black with moulded thread
D
D1
D2
H
T
(g)
WDS No.
M6
40
20
19
14
30
8199-201
M8
50
24
24
18
40
8199-202
M10
60
28
28
22
50
8199-203
'
'
'
7
+
Scallop Hand Screw
WDS 8210
MATERIAL
-
Thermoplastic black
Screw - Steel, zinc plated
D
D1
D2
H
H1
L
(g)
WDS No.
M6
40
18
24
13
20
20
8210-206
M6
40
18
24
13
30
24
8210-208
M6
40
18
24
13
50
32
8210-210
M8
40
18
24
13
20
24
8210-216
M8
40
18
24
13
30
28
8210-218
M8
40
18
24
13
40
32
8210-219
M8
50
22.5
32
18
30
31
8210-223
M8
50
22.5
32
18
50
37
8210-225
M12
63
22.5
40
28
30
40
8210-242
Scallop Hand Knob
WDS 8210
MATERIAL
-
Thermoplastic black
Insert- Steel, zinc plated
Note: Top cap is removable to create
through knob
D
D1
D2
H
H1
(g)
WDS No.
M6
40
18
24
13
16
8210-201
M8
40
18
24
13
16
8210-202
M8
50
22.5
32
18
20
8210-203
M10
50
22.5
32
18
22
8210-204
'
+
'
+
'
D1
L
H
D
H1
D2
