SECTION 5 - HAND KNOBS
WDS
WDS
www.wdsltd.co.uk5-93
&
0845 606 66 77
•
:
www.wdsltd.co.uk•
*
sales@wdsltd.co.ukClamp Grip - Female
Clamp Grip - Female
WDS 8475
WDS 8475
MATERIAL
-
Body - Thermoplastic
Insert - Steel - zinc plated
Insert - Stainless Steel - 303 S31
MATERIAL
-
Body - Thermoplastic
Insert - Steel - zinc plated
Insert - Stainless Steel - 303 S31
Traffic Red - RAL 3020
Cadmium Yellow - RAL 1021
D D1 D2 D3
H H1 H2
T
(g)
WDS No.
Steel Insert
WDS No.
Stainless Steel Insert
M8 50 22.2 28.2 34.8 17.8 11.5 14
30
8475-202TR 8475-302TR
M10 50 22.2 28.2 34.8 17.8 11.5 14
20
8475-204TR 8475-304TR
M12 50 22.2 28.2 34.8 17.8 11.5 18
10
8475-206TR 8475-306TR
M10 63 28 35.5 44 22.5 14.5 14
70
8475-208TR 8475-308TR
M12 63 28 35.5 44 22.5 14.5 18
50
8475-210TR 8475-310TR
M16 63 28 35.5 44 22.5 14.5 18
40
8475-212TR
-
D D1 D2 D3
H H1 H2
T
(g)
WDS No.
Steel Insert
WDS No.
Stainless Steel Insert
M8 50 22.2 28.2 34.8 17.8 11.5 14
30
8475-202CY
8475-302CY
M10 50 22.2 28.2 34.8 17.8 11.5 14
20
8475-204CY
8475-304CY
M12 50 22.2 28.2 34.8 17.8 11.5 18
10
8475-206CY
8475-306CY
M10 63 28 35.5 44 22.5 14.5 14
70
8475-208CY
8475-308CY
M12 63 28 35.5 44 22.5 14.5 18
50
8475-210CY
8475-310CY
M16 63 28 35.5 44 22.5 14.5 18
40
8475-212CY
-
'
'
'
7
'
+ +
+
'
'
'
7
'
+ +
+
ZP
303
RAL
3020
ZP
303
RAL
1021
