SECTION 1 - GRIPPERS
WDS
&
0845 606 66 77
•
:
www.wdsltd.co.uk•
*
sales@wdsltd.co.uk1-14
WDS
www.wdsltd.co.ukClamping Pad
Non Restricted
Swivel Ball
WDS 652
MATERIAL
-
Steel
Pad Hardened
Chemical Black Finish
Non-restricted Ball
These clamping pads are available with either a plain clamping face, or with a serrated clamping face
D
D1
L
S
P
(g)
WDS No. Plain WDS No. Serrated
M4
1.8
5.6
2
350
0.4
652-2004
-
M4
1.8
9.6
2
350
0.7
652-2005
-
M4
1.8
15.6
2
350
1.1
652-2006
-
M5
2.2
7.5
2.5
450
0.8
652-2007
-
M5
2.2
11.5
2.5
450
1.3
652-2008
-
M5
2.2
19.5
2.5
450
1.3
652-2009
-
M6
3.2
10
3
900
1
652-201
-
M6
3.2
16
3
900
3
652-202
-
M6
3.2
25
3
900
4
652-203
-
M8
4.5
10
4
1500
3
652-204
652-247
M8
4.5
12
4
1500
3
652-205
652-248
M8
4.5
20
4
1500
6
652-206
652-249
M8
4.5
30
4
1500
9
652-207
652-250
M10
6.0
12
5
2000
5
652-208
652-251
M10
6.0
16
5
2000
7
652-209
652-252
M10
6.0
25
5
2000
11
652-210
652-253
M10
6.0
35
5
2000
16
652-211
652-254
M12
7.2
16
6
3000
12
652-212
652-255
M12
7.2
20
6
3000
12
652-213
652-256
M12
7.2
30
6
3000
20
652-214
652-257
M12
7.2
40
6
3000
29
652-215
652-258
M16
10.7
20
8
6000
22
652-216
652-259
M16
10.7
25
8
6000
28
652-217
652-260
M16
10.7
35
8
6000
41
652-218
652-261
M16
10.7
50
8
6000
48
652-219
652-262
D
D1
L
S
NON-RESTRICTED BALL
P = Max load in KG
