SECTION 1 - GRIPPERS
WDS
&
0845 606 66 77
•
:
www.wdsltd.co.uk•
*
sales@wdsltd.co.uk1-18
WDS
www.wdsltd.co.ukHeaded Clamping
Pad - Restricted
Swivel Ball
WDS 652
MATERIAL
-
Steel
Pad Hardened
Chemical Black Finish
These clamping pads are available with either a plain clamping face, or with a serrated clamping face.
Pattern
D
D1
D2
L
L1
L2
S
P
(g)
WDS No.
Plain Ball
M6
3.2
10
20
6
3
5
600
6
652-60620
Plain Ball
M6
3.2
10
30
6
3
5
600
8
652-60630
Plain Ball
M6
3.2
10
40
6
16
5
600
1
652-60640
Plain Ball
M8
4.5
13
20
8
3.5
6
900
14
652-60820
Plain Ball
M8
4.5
13
35
8
3.5
6
900
17
652-60835
Plain Ball
M8
4.5
13
50
8
22
6
900
24
652-60850
Plain Ball
M10
6
16
25
10
4.5
8
1200
26
652-61025
Plain Ball
M10
6
16
40
10
4.5
8
1200
34
652-61040
Plain Ball
M10
6
16
60
10
28
8
1200
47
652-61060
Plain Ball
M12
7.2
18
30
12
5
10 1800
40
652-61230
Plain Ball
M12
7.2
18
50
12
5
10 1800
56
652-61250
Plain Ball
M12
7.2
18
80
12
44
10 1800
83
652-61280
Plain Ball
M16 10.7
24
40
16
6
14 3600
91
652-61640
Plain Ball
M16 10.7
24
60
16
6
14 3600
122
652-61660
Plain Ball
M16 10.7
24
80
16
36
14 3600
154
652-61680
Serrated Ball
M8
4.5
13
20
8
3.5
6
900
14
652-70820
Serrated Ball
M8
4.5
13
35
8
3.5
6
900
17
652-70835
Serrated Ball
M8
4.5
13
50
8
22
6
900
24
652-70850
Serrated Ball
M10
6
16
25
10
4.5
8
1200
26
652-71025
Serrated Ball
M10
6
16
40
10
4.5
8
1200
34
652-71040
Serrated Ball
M10
6
16
60
10
28
8
1200
47
652-71060
Serrated Ball
M12
7.2
18
30
12
5
10 1800
40
652-71230
Serrated Ball
M12
7.2
18
50
12
5
10 1800
56
652-71250
Serrated Ball
M12
7.2
18
80
12
44
10 1800
83
652-71280
Serrated Ball
M16 10.7
24
40
16
6
14 3600
91
652-71640
Serrated Ball
M16 10.7
24
60
16
6
14 3600
122
652-71660
Serrated Ball
M16 10.7
24
80
16
36
14 3600
154
652-71680
'
'
'
/
/
/
r
6 KH[
P = Max load in KG
