SECTION 1 - GRIPPERS
WDS
&
0845 606 66 77
•
:
www.wdsltd.co.uk•
*
sales@wdsltd.co.uk1-22
WDS
www.wdsltd.co.ukHexagon Body
Clamping Pads -
Diamond Faced
Gripper
WDS 653
MATERIAL
-
Body - Alloy Steel HRc43/46 -
Black Oxide finish
Ball - 300 series Stainless Steel
with a bonded Diamond face
(100 Grit equivalent)
The ball is held in place using
a Viton O-Ring which acts as
a seal to provide a smooth
movement whilst keeping
contaminants out.
D
D1
C
G
H
L
S
M
(g)
WDS No.
M6
6
10
28°
8
12
2
935
8
653-626012D
M6
6
10
28°
8
25
2
935
10
653-626025D
M6
6
10
28°
8
40
2
935
12
653-626040D
M8
8.5
13
28°
11.5
12
3
1550
18
653-628012D
M8
8.5
13
28°
11.5
25
3
1550
22
653-628025D
M8
8.5
13
28°
11.5
40
3
1550
26
653-628040D
G
C
HEX
D1
D
L
H S
M = Max Load (kg)
0.05
Hexagon Body
Clamping Pad -
Serrated Gripper
WDS 653
MATERIAL
-
Body - Alloy Steel HRc43/46 -
Black Oxide finish
Ball - M2 High Speed Steel
HRc60/62
The ball is held in place using
a Viton O-Ring which acts as
a seal to provide a smooth
movement whilst keeping
contaminants out.
D
D1
C
G
H
L
S
M
(g)
WDS No.
M6
6
10
28°
8
12
1.5
935
935
653-626012S
M6
6
10
28°
8
25
1.5
935
935
653-626025S
M6
6
10
28°
8
40
1.5
935
935
653-626040S
M8
8.5
13
24°
11.5
12
1.5
1550
1550
653-628012S
M8
8.5
13
24°
11.5
25
1.5
1550
1550
653-628025S
M8
8.5
13
24°
11.5
40
1.5
1550
1550
653-628040S
C
HEX
L
H S
D1
D
G
0.05
M = Max Load (kg)
