SECTION 1 - GRIPPERS
WDS
&
0845 606 66 77
•
:
www.wdsltd.co.uk•
*
sales@wdsltd.co.uk1-20
WDS
www.wdsltd.co.ukPlain Body
Clamping Pad -
Serrated Faced
Gripper
WDS 653
MATERIAL
-
Body - Alloy Steel HRc43/46 -
Black Oxide finish
Ball - M2 High Speed Steel
HRc60/62
The ball is held in place using
a Viton O-Ring which acts as
a seal to provide a smooth
movement whilst keeping
contaminants out.
D
D1
G
L
L1
S
T
M
(g) WDS No.
10
6
28°
10.5
3.5
1.5
M4
1175
5 653-611012S
10
6
28°
23.5
9
1.5
M4
1175
12 653-611025S
13
8.5
24°
14.5
6.5
1.5
M5
2020
13 653-611316S
13
8.5
24°
23.5
9
1.5
M5
2020
21 653-611325S
17
10
42°
18
7.5
4
M6
2800
31 653-611722S
19
12
45°
20
8.5
4
M8
3950
42 653-611924S
24
16
40°
24
9
4
M10
5950
1000 653-612428S
G
D1
D
L1
L
S
T
0.05
0.25
+0.00
-0.13
M = Max Load (kg)
Plain Body Clamping
Pad - Urethane Faced
Gripper
WDS 653
MATERIAL
-
Body - Alloy Steel HRc43/46 - Black
Oxide finish
Ball - 300 series Stainless Steel with
a bonded Urethane pad (Durometer
Rating 60)
The ball is held in place using a Viton
O-Ring which acts as a seal to provide
a smooth movement whilst keeping
contaminants out.
D
D1
G
L
L1
S
T
(g)
WDS No.
10
10
28°
10.5
3.5
4
M4
6
653-611012U
10
10
28°
23.5
9
4
M4
13
653-611025U
13
13
28°
14.5
6.5
5
M5
15
653-611316U
13
13
28°
23.5
9
5
M5
23
653-611325U
17
16
28°
18
7.5
5
M6
32
653-611722U
19
21
24°
20
8.5
6
M8
46
653-611924U
24
23
24°
24
9
6
M10
85
653-612428U
G
D1
D
L
L1
S
T
0.05
0.25
+0.00
-0.13
