Clamping Pad -
Serrated Gripper
WDS 653
MATERIAL
-
Body - Alloy Steel HRc43/46 -
Black Oxide finish
Ball - M2 High Speed Steel
HRc60/62
The ball is held in place using
a Viton O-Ring which acts as
a seal to provide a smooth
movement whilst keeping
contaminants out.
D
D1
G
L
S
M
(g)
WDS No.
M10
4
28°
25
1.5
-
10
653-6310025S
M10
4
28°
35
1.5
-
14
653-6310035S
M10
4
28°
50
1.5
-
22
653-6310050S
M12
6
28°
25
1.5
1550
10
653-6312025S
M12
6
28°
35
1.5
1550
20
653-6312035S
M12
6
28°
50
1.5
1550
32
653-6312050S
M16
8.5
24°
25
1.5
2350
25
653-6316025S
M16
8.5
24°
35
1.5
2350
38
653-6316035S
M16
8.5
24°
50
1.5
2350
58
653-6316050S
G
D
D1
L
S
M = Max Load (kg)
Threaded Body
Clamping Pad -
Urethane Gripper
WDS 653
MATERIAL
-
Body - Alloy Steel HRc43/46 -
Black Oxide finish
Ball - 300 series Stainless Steel
with a bonded Urethane pad
(Durometer Rating 60)
The ball is held in place using
a Viton O-Ring which acts as
a seal to provide a smooth
movement whilst keeping
contaminants out.
D
D1
G
L
S
(g)
WDS No.
M10
8
28°
25
3.5
10
653-6310025U
M10
8
28°
35
3.5
14
653-6310035U
M10
8
28°
50
3.5
22
653-6310050U
M12
10
28°
25
4
15
653-6312025U
M12
10
28°
35
4
21
653-6312035U
M12
10
28°
50
4
33
653-6312050U
M16
13
28°
25
5
27
653-6316025U
M16
13
28°
35
5
40
653-6316035U
M16
13
28°
50
5
60
653-6316050U
G
D1
D
L
S
