sales@wdsltd.co.ukClamping Screw
Pad - Restricted
Swivel Ball
WDS 652
MATERIAL
-
Steel, Pad Hardened Chemical
Black Finish
Pattern
D
D1
L
S
P
(g)
WDS No.
Plain
M6
3.2
12
3
600
1.8
652-40612
Plain
M6
3.2
16
3
600
2.4
652-40616
Plain
M6
3.2
25
3
600
3.9
652-40625
Plain
M8
4.5
16
4
900
4.1
652-40816
Plain
M8
4.5
20
4
900
5.7
652-40820
Plain
M8
4.5
30
4
900
8.7
652-40830
Plain
M10
6
20
5
1200
8.7
652-41020
Plain
M10
6
25
5
1200
11.2
652-41025
Plain
M10
6
35
5
1200
16.2
652-41035
Plain
M12
7.2
20
6
1800
11
652-41220
Plain
M12
7.2
30
6
1800
19.6
652-41230
Plain
M12
7.2
40
6
1800
28.5
652-41240
Plain
M16
10.7
35
8
3600
41
652-41635
Plain
M16
10.7
50
8
3600
48
652-41650
Serrated
M8
4.5
16
4
900
4.1
652-50816
Serrated
M8
4.5
20
4
900
5.7
652-50820
Serrated
M8
4.5
30
4
900
8.7
652-50830
Serrated
M10
6
20
5
1200
8.7
652-51020
Serrated
M10
6
25
5
1200
11.2
652-51025
Serrated
M10
6
35
5
1200
16.2
652-51035
Serrated
M12
7.2
20
6
1800
11
652-51220
Serrated
M12
7.2
30
6
1800
19.6
652-51230
Serrated
M12
7.2
40
6
1800
28.5
652-51240
Serrated
M16
10.7
35
8
3600
41
652-51635
Serrated
M16
10.7
50
8
3600
48
652-51650
P = Max load in kg
'
'
/
