SECTION 1 - GRIPPERS
WDS
WDS
www.wdsltd.co.uk1-21
&
0845 606 66 77
•
:
www.wdsltd.co.uk•
*
sales@wdsltd.co.ukPlain Body
Clamping Pad -
Diamond Faced
Gripper
WDS 653
MATERIAL
-
Body - Alloy Steel HRc43/46 -
Black Oxide finish
Ball - 300 series Stainless Steel
with a bonded Diamond face
(100 Grit equivalent)
The ball is held in place using
a Viton O-Ring which acts as
a seal to provide a smooth
movement whilst keeping
contaminants out.
D
D1
G
L
L1
S
T
M
(g)
WDS No.
10
8
28°
10.5
3.5
2
M4
1175
6
653-611012D
10
8
28°
23.5
9
2
M4
1175
13
653-611025D
13
11
28°
14.5
6.5
3
M5
2020
15
653-611316D
13
11
28°
23.5
9
3
M5
2020
23
653-611325D
17
14
28°
18
7.5
3
M6
2800
31
653-611722D
19
19
24°
20
8.5
4
M8
3950
45
653-611924D
24
21
24°
24
9
4
M10
5950
84
653-612428D
G
D1
D
L
S
L1
T
M = Max Load (kg)
0.25
0.05
+0.00
-0.13
Hexagon Body
Clamping Pads -
Urethane Gripper
WDS 653
MATERIAL
-
Body - Alloy Steel HRc43/46 -
Black Oxide finish
Ball - 300 series Stainless Steel
with a bonded Urethane pad
(Durometer Rating 60)
The ball is held in place using
a Viton O-Ring which acts as
a seal to provide a smooth
movement whilst keeping
contaminants out.
D
D1
C
G
H
L
S
(g)
WDS No.
M6
6
10
28°
8
12
4
8
653-626012U
M6
6
10
28°
8
25
4
10
653-626025U
M6
6
10
28°
8
40
4
12
653-626040U
M8
8.5
13
28°
11.5
12
5
18
653-628012U
M8
8.5
13
28°
11.5
25
5
22
653-628025U
M8
8.5
13
28°
11.5
40
5
26
653-628040U
C
HEX
D
L
H
D1
S
G
0.05
