SECTION 1 - GRIPPERS
WDS
WDS
www.wdsltd.co.uk1-17
&
0845 606 66 77
•
:
www.wdsltd.co.uk•
*
sales@wdsltd.co.ukThreaded Body
Clamping Pad -
Diamond Faced
Gripper
WDS 653
MATERIAL
-
Body - Alloy Steel HRc43/46 -
Black Oxide finish
Ball - 300 series Stainless Steel
with a bonded Diamond Face
(100 Grit Equivalent)
The ball is held in place using
a Viton O-Ring which acts as
a seal to provide a smooth
movement whilst keeping
contaminants out.
D
D1
G
L
S
M
(g)
WDS No.
M10
6
28°
25
1.5
-
10
653-6310025D
M10
6
28°
35
1.5
-
14
653-6310035D
M10
6
28°
50
1.5
-
22
653-6310050D
M12
8
28°
25
2.0
1550
10
653-6312025D
M12
8
28°
35
2.0
1550
21
653-6312035D
M12
8
28°
50
2.0
1550
33
653-6312050D
M16
11
28°
25
3.0
2350
27
653-6316025D
M16
11
28°
35
3.0
2350
40
653-6316035D
M16
11
28°
50
3.0
2350
60
653-6316050D
G
L
S
D1
D
M = Max Load (kg)
