SECTION 22 - EYE BOLTS & HOIST RINGS
WDS
WDS
www.wdsltd.co.uk22-1
&
0845 606 66 77
•
:
www.wdsltd.co.uk•
*
sales@wdsltd.co.ukCollared
Eye Bolts To
BS4278:1
WDS 695
MATERIAL
-
Steel to BS970:080A27 (EN5A)
Forged, hardened and tempered
CE marked
Batch coded for identification
Marked with SWL for axial
loads
Supplied with an EC Declaration
of Conformity and Test
Certificate
Refer to Instructions for Safe
Use of Eyebolts on pages 22-2
and 22-3
D
H G
E
F
B
SWL
D
B
E
F
G
H SWL (kg)
Ø
0
°
-30
°
Ø
31
°
-60
°
Ø
61
°
-90
°
(g)
WDS No.
M8
22
15
9
20
18
150
-
-
-
60
695-427808
M10
22
15
9
20
18
250
320
200
130
70
695-427810
M12
22
15
9
20
18
400
500
320
200
70
695-427812
M16
29
20
12
26
23
800
1000
640
400
160 695-427816
M20
40
27
16
36
32
1600
2000
1250
800
440 695-427820
Note: 695-427808 / 695-427810 ARE NOT RECOMMENDED FOR LIFTING
Lifting equipment must be specified by a competent trained person
