SECTION 22 - EYE BOLTS & HOIST RINGS
WDS
&
0845 606 66 77
•
:
www.wdsltd.co.uk•
*
sales@wdsltd.co.uk22-6
WDS
www.wdsltd.co.ukHoist Ring
Side Pull Hoist Ring
WDS 695
WDS 695
MATERIAL
-
Alloy steel
Chemical black finish
Full swivel and pivot action
Supplied with Certificate of
Proof Test
MATERIAL
-
Alloy Steel
Chemical black finish
Supplied with Certificate of Proof
Test
A B C D F G H J K L M N O R S P
(kg) WDS No.
M8 33 16 21 14 8 25 52 44 76 19 13 13 25 -
325 0.25 695-501
M10 33 20 21 14 8 25 52 44 76 19 13 13 25 -
500 0.25 695-503
M12 48 24 35 21 13 44 75 51 110 32 19 22 38 6 725 1.0 695-505
M16 48 32 35 21 13 44 75 51 110 32 19 22 38 8 1400 1.0 695-507
M20 59 40 48 26 16 57 102 67 145 44 25 29 51 10 2290 2.0 695-509
M24 59 48 48 26 16 57 102 67 145 44 25 29 51 12 3050 2.0 695-511
M30 90 60 83 42 27 95 196 111 265 76 49 48 76 19 4850 9.0 695-513
M36 90 72 83 42 27 95 196 111 265 76 49 48 76 19 7500 9.0 695-515
M48 90 96 83 42 27 95 196 111 265 76 49 48 76 19 10000 10.0 695-517
P = Load capacity kg
*
&
%
'
)
( UDG
$
.
+
0
6
-
5
% &
*
1
/
2
'
)
$
A
Load
Capacity (kg)
B
C
D
E
F
G
Thread
Torque (kg.m)
(kg) WDS No.
M8
400
67.8 12.5 19.0 10.9
9.7
46.7
1.0
0.17 695-201
M10
450
67.8 17.5 19.0 10.9
9.7
46.7
1.7
0.17 695-202
M12
1050
121.4 19.0 38.1 22.4 19.0 89.4
3.8
1.08 695-203
M16
1900
121.4 29.0 38.1 22.4 19.0 89.4
8.2
1.12 695-204
M20
2150
121.4 34.0 38.1 22.4 19.0 89.4
13.6
1.19 695-205
M20
3000
165.6 32.0 58.7 35.6 25.4 130.6
13.6
3.03 695-206
M24
4200
165.6 37.0 58.7 35.6 25.4 130.6
31.0
3.10 695-207
Lifting equipment must be specified by a competent trained person
Lifting equipment must be specified by a competent trained person
