sales@wdsltd.co.ukSpring Plungers
- Plastic Body &
Ball
WDS 843
MATERIAL
-
Body - Plastic
Ball - White Delrin
Spring - 1.4310
D
D1
E
L
L1
P1
P2
(g)
WDS No.
M6
3.5
1
14
1
0.9
1.3
1
843-206
M8
5
1.2
16
1.5
1.5
3
1
843-208
M10
6
1.6
19
2
2
4
2
843-210
E
D
L
D1
L1
P1 = Spring load (initial)kgf
P2 = Spring Load (final) kgf
Spring Plungers
- Plastic body &
Stainless Ball
WDS 843
MATERIAL
-
Body - Plastic
Ball - Stainless 1.4034 Hardened
Spring - 1.4310
D
D1
E
L
L1
P1
P2
(g)
WDS No.
M6
3.5
1
14
1
0.9
1.3
1
843-606
M8
5
1.2
16
1.5
1.5
3
1
843-608
M10
6
1.6
19
2
2
4
2
843-610
E
D
L
D1
L1
P1 = Spring load (initial)kgf
P2 = Spring Load (final) kgf
