SECTION 2 - LOCATION & POSITIONING
WDS
WDS
www.wdsltd.co.uk2-45
&
0845 606 66 77
•
:
www.wdsltd.co.uk•
*
sales@wdsltd.co.ukBall Spring
Plunger
WDS 838
MATERIAL
-
Body: Stainless Steel
Spring: 1.4310 301S21
Ball: 1.4034 420S45
P1 = Spring End loading kgf (Initial)
P2 = Spring End loading kgf (Final)
D
D1
D2
L
L1
L2
Initial P1 Final P2
(g)
WDS No.
Stainless Body
3
2.5
3.5
4
0.8
0.7
0.17
0.34
0.18
838-2003
4
3
4.6
5
1
0.7
0.3
0.7
0.3
838-201
5
4
5.6
6
1
1
0.3
0.7
0.6
838-202
6
5
6.5
7
1
1.5
0.6
1.2
1
838-203
8
6.5
8.5
9
1
1.8
0.6
1.2
2
838-204
10
8
12
13.5
2.5
2.7
1.0
2
6
838-205
12
10
14
16
2.5
3.5
1.5
2.5
10
838-206
'
/
/
' %DOO
'
/
'
/
/
' %DOO
'
/
