SECTION 2 - LOCATION & POSITIONING
WDS
WDS
www.wdsltd.co.uk2-51
&
0845 606 66 77
•
:
www.wdsltd.co.uk•
*
sales@wdsltd.co.ukLateral Spring
Retainer Steel
Pin without Seal
WDS 290
MATERIAL
-
Body: Aluminium
Spring: Steel
Pressure Pin: Galvanized steel
Lateral Spring Retainer with
steel pin, without seal for dry
use
D
D1
D2
+0.1
L
L1
-1.0
F Max
X
P Max
(g)
WDS No.
6
3
6
4.0
7
0.5
0.9
2.0
1
290-201
10
5
10
6.7
11
0.8
1.6
5.0
2
290-203
10
6
10
10.7
11
1.0
1.8
7.5
2
290-205
12
8
12
13.9
13
1.3
2.6
10.0
8
290-207
16
10
16
16.7
17
1.6
3.2
20.0
16
290-209
Spring retainers are used for positioning, clamping, holding and locating workpieces for:- engraving, marking, drilling, welding, soldering, assembling, tapping, polishing etc.
See WDS 295 for eccentric bushes for use in conjunction with Lateral Spring Retainers for fine positioning to the workpiece.
3
3
'
'
/
)
/
'
3 )RUFH LQ NJI
;
Lateral Spring
Retainer Steel Pin
with Seal
WDS 290
MATERIAL
-
Body: Aluminium
Spring: Steel
Pressure Pin: Galvanized steel
Lateral Spring Retainer with
steel pin, with seal for wet use
D
D1
D2
+0.1
L
L1
-1.0
F Max
X
P Max
(g)
WDS No.
6
3
6
4
7
0.5
0.9
2.0
1
290-301
10
5
10
6
12
0.8
1.6
5.0
2
290-303
10
6
10
10
12
1.0
1.8
7.5
2
290-305
12
8
12
13
14
1.3
2.6
10.0
8
290-307
16
10
16
16
18
1.6
3.2
20.0
16
290-309
Spring retainers are used for positioning, clamping, holding and locating workpieces for:- engraving, marking, drilling, welding, soldering, assembling, tapping, polishing etc.
See WDS 295 for eccentric bushes for use in conjunction with Lateral Spring Retainers for fine positioning to the workpiece.
3
3
'
'
/
)
/
'
3 )RUFH LQ NJI
;
