SECTION 2 - LOCATION & POSITIONING
WDS
&
0845 606 66 77
•
:
www.wdsltd.co.uk•
*
sales@wdsltd.co.uk2-48
WDS
www.wdsltd.co.uk303
'
'
/
/
+
'
6
3 ,QLWLDO 6SULQJ )RUFH NJI
3 )LQDO 6SULQJ )RUFH NJI
Spring Plunger with
Hexagon Head
WDS 622/
842
MATERIAL
-
Body: Steel, Chemical Black Finish
or Stainless Steel
Ball: Steel or Stainless Steel,
Hardened
Maximum durable temp is 180°C
D
D1
D2
L
L1
H
P1
P2
(g)
Steel
WDS No.
Stainless Steel
WDS No.
M6 3.5
10
16
12
1
0.88 1.27
4
622-206
842-206
M8
5
13
21
16
1.5 1.47 2.94
9
622-208
842-208
M10
6
16
26
20
2
1.96 3.43
17
622-210
842-210
M12
8
18
32
25
2.5 2.94 5.39
28
622-212
842-212
