SECTION 2 - LOCATION & POSITIONING
WDS
&
0845 606 66 77
•
:
www.wdsltd.co.uk•
*
sales@wdsltd.co.uk2-44
WDS
www.wdsltd.co.ukStainless Steel
Spring Plunger
with Thrust Pin
WDS 823
MATERIAL
-
Body - Stainless Steel 1.4305
Thrust Pin - Stainless Steel
1.4034 Hardened
Spring - Stainless Steel 1.4310
Hexagon Socket
1.5
L
1.5
D
D1 (d9)
L1
P1 = Spring load (initial)kgf
P2 = Spring Load (final) kgf
D
D1
L
L1
P1
P2
(g)
WDS No.
M3
1
10
1.5
0.05
0.3
1
823-2003
M4
1.5
15
1.5
0.5
1.63
1
823-2004
M5
2.4
18
2.3
0.6
2.04
2
823-2005
M6
2.7
20
2.5
0.7
2.04
3
823-2006
M8
3.5
22
3
0.92
3.57
4
823-2008
M10
4
22
3
0.92
3.57
9
823-2010
M12
6
28
4
1.02
5.61
16
823-2012
M16
7.5
32
5
4.58
10.2
34
823-2016
Stainless Steel
Spring Plunger
with Nylon Thrust
Pin
WDS 823
MATERIAL
-
Body - Stainless Steel 1.4305
Thrust Pin - Nylon
Spring - Stainless Steel 1.4310
Hexagon Socket
1.5
L
1.5
D
D1 (d9)
L1
P1 = Spring load (initial)kgf
P2 = Spring Load (final) kgf
D
D1
L
L1
P1
P2
(g)
WDS No.
M3
1
10
1.5
0.05
0.31
8
823-2503
M4
1.5
15
1.5
0.51
1.63
1
823-2504
M5
2.4
18
2.3
0.61
2.04
9
823-2505
M6
2.7
20
2.5
0.71
2.04
2
823-2506
M8
3.5
22
3
0.92
3.57
5
823-2508
M10
4
22
3
0.92
3.57
8
823-2510
M12
6
28
4
1.02
5.61
14
823-2512
M16
7.5
32
5
4.58
10.2
31
823-2516
