SECTION 7 - LEVELLING FEET
WDS
WDS
www.wdsltd.co.uk7-45
&
0845 606 66 77
•
:
www.wdsltd.co.uk•
*
sales@wdsltd.co.ukStainless Steel
316 Hygienic
Plastic Covered
Base Levelling
Feet with
Optional Bolt
Down
WDS 890
D2
B
D1
D
H
L
10°
10°
S a/f
19
MATERIAL
-
316 Stainless Steel
P1 = Pull Load (Max)
P2 = Compresive Load (Max)
D
D1
L
H
S
C
D2
P1 (KN)
P2 (KN)
(g)
WDS No.
M12
80
98
31
10
53
8.5
0.3
15
140
890-512100B
M12
80
140
31
10
53
8.5
0.3
10.8
180
890-512150B
M16
80
98
31
13
53
8.5
0.3
15
200
890-516100B
M16
80
140
31
13
53
8.5
0.3
15
250
890-516150B
M16
80
173
31
13
53
8.5
0.3
15
320
890-516180B
M12 100
98
36
10
63
11
0.3
16.5
180
890-512100C
M12 100 140
36
10
63
11
0.3
108
220
890-512150C
M16 100
98
36
13
63
11
0.3
20
240
890-516100C
M16 100 140
36
13
63
11
0.3
20
290
890-516150C
M16 100 173
36
13
63
11
0.3
20
360
890-516180C
