SECTION 7 - LEVELLING FEET WDS
& 0845 606 66 77 • : • * 7-44
WDS
Stainless
Steel 316 Bolt
Down Hygienic
Levelling Feet -
Non Slip
WDS 890
B
15
D
L
D1
H
10° 10°
S a/f
MATERIAL -
316 Stainless Steel
EHEDG Certified
P1 = Pull Load (Max)
P2 = Compresive Load (Max)
D D1 L H B S P1 (KN) P2 (KN) (g) WDS No.
M12 80 97 39 53.2 10 4 15 310 890-412100B
M12 80 139 39 53.2 10 4 10.9 350 890-412150B
M12 80 172 39 53.2 10 4 7.1 380 890-412180B
M16 80 97 39 53.2 13 4 15 370 890-416100B
M16 80 139 39 53.2 13 4 15 420 890-416150B
M16 80 172 39 53.2 13 4 15 530 890-416180B
M16 105 97 39 70 13 4 22 560 890-416100C
M16 105 139 39 70 13 4 22 610 890-416150C
M16 105 172 39 70 13 4 22 720 890-416180C
