SECTION 7 - LEVELLING FEET WDS
& 0845 606 66 77 • : • * 7-42
WDS
D D1 D2 H H1 H2 F S Max Load (Kg) (g) WDS No.
M12 100 78 207 35 7.5 8 22 280 710 693-12100
M16 140 114 221 42 8.5 10 24 1200 1695 693-16140
M20 190 158 228 54 8.5 12 27 3000 3585 693-20190
Anti-vibration
Levelling Foot -
Medium Duty
WDS 693
MATERIAL -
Body - Melamine Coating
Screw - Steel Zinc Plated
(Steel Grade 1.0040)
P = Safe working load in kilograms (for static load only)
'
'
+
+
+
5HPRYDEOH
DGMXVWLQJ QXW
'
)
6
ZP
