SECTION 7 - LEVELLING FEET
WDS
WDS
www.wdsltd.co.uk7-39
&
0845 606 66 77
•
:
www.wdsltd.co.uk•
*
sales@wdsltd.co.ukSwivel Pad
WDS 674
MATERIAL
-
Nut and Pad - Steel BS.970
Gr.220M07 Chemical Black Finish
Note: This part to be used for static
compressive loading only
P = safe working load in kg (for static load only)
D
D1
L
L1
S
T
P
(g)
WDS No.
M6
25
18
4
10
8
900
30
674-206
M8
30
22
5
13
9
1700
50
674-208
M10
35
24
5
17
10
2100
75
674-210
M12
38
26
6
19
12
3700
105
674-212
M16
50
30
6
24
14
4600
150
674-216
M20
63
40
7
30
18
5400
300
674-220
Type A - Steel Pad
'
6 D I
'
/
/
7
r 0D[
3 6DIHZRUNLQJ ORDG LQ NJ
IRU VWDWLF FRPSUHVVLYH ORDG RQO\
Swivel Pad
WDS 674
MATERIAL
-
Nut - Stainless Steel BS.970
Gr.303S31
Pad - White POM
(Polyoxymethylene) Material
Note: This part to be used for static
compressive loading only
D
D1
L
L1
S
T
P
(g)
WDS No.
M6
20
14
2.5
10
5
400
10
674-151
M8
25
18
4
13
7
700
14
674-152
M10
32
22
5
17
9
1000
23
674-153
M12
40
26
6
19
11
1800
50
674-154
M16
50
32
7
24
13
2000
70
674-155
M20
60
42
8
30
17
2200
90
674-156
'
6 D I
'
/
/
7
r 0D[
3 6DIHZRUNLQJ ORDG LQ NJ
IRU VWDWLF FRPSUHVVLYH ORDG RQO\
303
P = safe working load in kg (for static compressive load only)
