SECTION 7 - LEVELLING FEET
WDS
&
0845 606 66 77
•
:
www.wdsltd.co.uk•
*
sales@wdsltd.co.uk7-40
WDS
www.wdsltd.co.ukSwivel Pad
WDS 674
MATERIAL
-
Nut - Stainless Steel BS.970
Gr.303S31
Pad - White Plastic (Sustarin C)
Note: This part to be used for static
compressive loading only
P = safe working load in kg (for static compressive load only)
D
D1
L
L1
S
T
P
(g)
WDS No.
M6
20
14
2.5
10
5
400
10
674-251
M8
25
18
4
13
7
700
14
674-252
M10
32
22
5
17
9
1000
23
674-253
M12
40
26
6
19
11
1800
50
674-254
M16
50
32
7
24
13
2000
70
674-255
M20
60
42
8
30
17
2200
90
674-256
Type B - Sustarin C Plastic Pad
'
6 D I
'
/
/
7
r 0D[
3 6DIHZRUNLQJ ORDG LQ NJ
IRU VWDWLF FRPSUHVVLYH ORDG RQO\
303
Swivel Pad
WDS 609
MATERIAL
-
Steel BS.970 Gr.220M07
Chemical black finish
Note: This part to be used for
compressive loading only
D
D1
B
L
L1
S
T
P
(g)
WDS No.
M5
13
4
18
11
10
6
530
15
609-2005
M6
13
4
18
11
10
8
760
21
609-201
M8
16
4
21
14
13
9
1370
29
609-202
M10
19
4
22
15
17
10
2170
35
609-203
M12
22
5
25
17
19
12
3160
49
609-204
M16
25
5
30
20
24
14
5820
80
609-206
M20
32
8
36
22
30
18
7000
145 609-207
Metric
Inch
D
D1
B
L
L1
S
T
P
(g)
BSW
WDS No.
UNC
WDS No.
BSW UNC
3
⁄
8
19
4
22.2
15 0.709"
-
9.5
2170
35 609-04
-
1
⁄
2
22.2
4.8
25
17.5 0.820" 0.750"
11.1 3160
55
-
609-20
3
⁄
4
31.8
7.9
36.5
22.2
-
1.125"
18.3 6900
140
-
609-22
1
41.3
9.5
51
31.8 1.480"
-
27
8500
340 609-08
-
P = safe working load in kg (for static load only)
'
/
/
%
