SECTION 7 - LEVELLING FEET WDS
WDS
7-43 & 0845 606 66 77 • : • *
D D1 L L1 Max L1 Min H S P1 (KN) P2 (KN) (g) WDS No.
M16 105 184 146 110 34 13 4 22 760 890-216150C
M16 105 244 140 206 34 13 4 22 900 890-216210C
Stainless Steel
316 Hygienic
Levelling Feet -
EHEDG Certified
WDS 890
D1
H
L1
L
D
10° 10°
S a/f
MATERIAL -
316 Stainless Steel
EHEDG Certified
P1 = Pull Load (Max)
P2 = Compresive Load (Max)
D D1 L H S P1 (KN) P2 (KN) (g) WDS No.
M12 80 97 39 10 4 15 290 890-312100B
M12 80 139 39 10 4 10.9 330 890-312150B
M12 80 172 39 10 4 7.1 360 890-312180B
M16 80 97 39 13 4 15 350 890-316080B
M16 80 139 39 13 4 15 400 890-316150B
M16 80 172 39 13 4 15 510 890-316180B
M16 105 97 39 13 4 22 540 890-316100C
M16 105 139 39 13 4 22 590 890-316150C
M16 105 172 39 13 4 22 700 890-316180C
Stainless Steel
316 Hygienic
Levelling Feet -
Non Slip
WDS 890 D
L
D1
H
10° 10°
S a/f
MATERIAL -
316 Stainless Steel
EHEDG Certified
P1 = Pull Load (Max)
P2 = Compresive Load (Max)
