SECTION 14 - GAS STRUTS & END FITTINGS
WDS
&
0845 606 66 77
•
:
www.wdsltd.co.uk•
*
sales@wdsltd.co.uk14-12
WDS
www.wdsltd.co.ukGas Struts with
Swivel Eye Rose
Joints
WDS 550
MATERIAL
-
Body - Steel, Black Powder
Coated
Rod - Steel Nitride and Black
Adjusting Valve - Brass
Adjustable Force - Supplied at
maximum force to be adjusted
in position to suit the specific
application.
See also the full range of end
fittings to suit your
application.
A
B
L1
L
L2
L2
D
D
E
E
Pressure releasing
screw in brass end
A
B
D
E
L
L1
L2
S
T
Force
Range
Rod Dia Body Dia
Stroke
Rod End
Thread
Rod End
Thread
Length
Newtons
(kg)
WDS No.
6
15
6
9
172 60
30 M6x1.0 9
20-400 0.18 550-0615060RR
6
15
6
9
252 100
30 M6x1.0 9
20-400 0.205 550-0615100RR
6
15
6
9
352 150
30 M6x1.0 9
20-400 0.235 550-0615150RR
6
15
6
9
452 200
30 M6x1.0 9
20-400 0.265 550-0615200RR
8
19
6
9
252 100
30 M6x1.0 9
50-700 0.28 550-0819100RR
8
19
6
9
352 150
30 M6x1.0 9
50-700 0.33 550-0819150RR
8
19
6
9
452 200
30 M6x1.0 9
50-700 0.39 550-0819200RR
8
19
6
9
552 250
30 M6x1.0 9
50-700 0.44 550-0819250RR
10
22
8
12 457 200
36 M8x1.25 12 100-1200 0.621 550-1022200RR
10
22
8
12 557 250
36 M8x1.25 12 100-1200 0.696 550-1022250RR
10
22
8
12 657 300
36 M8x1.25 12 100-1200 0.761 550-1022300RR
10
22
8
12 857 400
36 M8x1.25 12 100-1200 0.906 550-1022400RR
14
28
10
14 462 200
43 M10x1.5 14 200-2500 1.076 550-1428200RR
14
28
10
14 662 300
43 M10x1.5 14 200-2500 1.331 550-1428300RR
14
28
10
14 862 400
43 M10x1.5 14 200-2500 1.596 550-1428400RR
14
28
10
14 1062 500
43 M10x1.5 14 200-2500 1.851 550-1428500RR
