SECTION 14 - GAS STRUTS & END FITTINGS
WDS
&
0845 606 66 77
•
:
www.wdsltd.co.uk•
*
sales@wdsltd.co.uk14-16
WDS
www.wdsltd.co.uk/
/
'
/
&
%
$
'
$
/
/
'
/
&
%
$
'
$
Clevis Fork
WDS 551/851
MATERIAL
-
Steel Zinc Plated or 304 Stainless Steel
DIN 71752 end fitting for Gas Struts. Can be
utilised on applications such as industrial
machinery and enclosures.
WDS No.
A
A1
B
C
D
D1
L
L1
L2
(g) Steel Zinc Plated Stainless Steel
10
10
5
10
M5
9
26
20
7.5
9 551-205
851-205
12
12
6
12
M6
10
31
24
9
15 551-206
851-206
16
16
8
16
M8
14
42
32
12
37 551-208
851-208
20
20
10
20 M10 18
52
40
15
74 551-210
851-210
24
24
12
24 M12 20
62
48
18 121 551-212
851-212
Spring Bolt
WDS 551
MATERIAL
-
Steel Zinc Plated
Steel zinc plated spring bolt end fittings allow
swift installation when used with Clevis Fork.
A
B
C
D
L
L1
(g)
Suitable for
use with
WDS No.
9
5
12
5
19
5.5
2.54
551-205
551-305
10
6
14
6
23
6.5
4.6
551-206
551-306
14
8
19
8
30
8
10.6
551-208
551-308
18
10
23
10
38
10
19.4
551-210
551-310
20
12
28
12
45
12
33
551-212
551-312
Clevis Eye
WDS 551/851
MATERIAL
-
Steel Zinc Plated or 304 Stainless Steel
DIN 71752 Mating Part
Clevis eye attachments can be used on
applications such as industrial machinery and
inspection hatches.
WDS No.
A
B
C
D
D1
L
L1
T
(g)
Steel Zinc Plated Stainless Steel
10
5
7.5
M5
5
26
20
8
12 551-405
851-405
12
6
9
M6
6
31
24
11
21 551-406
851-406
16
8
12
M8
8
42
32
14
51 551-408
851-408
20
10
15
M10
10
52
40
18
98 551-410
851-410
24
12
18
M12
12
62
48
22
168 551-412
851-412
/
&
'
/
%
$
'
/
7
/
&
%
'
$
ZP
304
ZP
ZP
304
