SECTION 14 - GAS STRUTS & END FITTINGS
WDS
&
0845 606 66 77
•
:
www.wdsltd.co.uk•
*
sales@wdsltd.co.uk14-20
WDS
www.wdsltd.co.ukGas Strut
Mounting
Bracket - Flat
with Ball Stud
WDS 551
MATERIAL
-
Zinc Plated Steel
T
D
H
G
C
B
R7.5
4.3
6.5
A
F
E
To Suit
Gas Strut No.
A
B
C
D
E
F
G
H
T
(g)
WDS No.
550-0615***/550-0819*** 70 55 25 10 30 48.5 20 5.5 2.5
50
551-716
550-1022***
70 55 25 13 30 48.5 20 5.5 2.5
55
551-718
Gas Strut
Mounting
Brackets - Folded
with Internal Ball
Stud
WDS 551
MATERIAL
-
Zinc Plated Steel
T G
D
E
A
F
C
B
J
H
4.3
6.5
R7.5
To Suit
Gas Strut No.
A B C D E
F
G H J
T
(g)
WDS No.
550-0615***/550-0819*** 70
55
25
10
20
29.7
12
24.2
17
2.5 50
551-726
550-1022***
70
55
25
13
20
29.7
14
24.2
17
2.5 55
551-728
Gas Strut
Mounting
Bracket - Folded
with External
Ball Stud
WDS 551
MATERIAL
Zinc Plated Steel
D
G T
A
E
F
B
C
H
J
4.3
6.5
R7.5
To Suit
Gas Strut No.
A B C D E
F
G H J
T
(g)
WDS No.
550-0615***/550-0819*** 70
55
25
10
20
29.7
12
24.2
17
2.5
50
551-736
550-1022***
70
55
25
13
20
29.7
14
24.2
17
2.5
55
551-738
For instructions of use with a Gas Strut see page 14-19
For instructions of use with a Gas Strut see page 14-19
For instructions of use with a Gas Strut see page 14-19
