WDS GAS STRUT MOUNTING BRACKETS

INSTRUCTIONS FOR USE

Release the Safety Pin

Withdraw the Safety Pin and retain

Pull the Ball Stud from the socket. The Ball

Stud is retained by a Spring Clip so some

force will be needed.

Firmly press the socket onto the Bracket Ball

until it ‘clicks’ fully home. Re-insert the Safety

Pin and clip into place.
