SECTION 14 - GAS STRUTS & END FITTINGS
WDS
WDS
www.wdsltd.co.uk14-17
&
0845 606 66 77
•
:
www.wdsltd.co.uk•
*
sales@wdsltd.co.ukClevis Pin
WDS 551/851
MATERIAL
-
Steel Zinc Plated or 304 Stainless Steel
Pins should be used with an E-clip DIN6799 to
secure the gas spring to your application.
WDS No.
D
D1
D2
C
H
L
L1
(g)
Steel Zinc Plated Stainless Steel
5
4
8
0.74
1.5
13
10.5
2.4 551-505
851-505
6
5
9
0.74
1.5
15.5
12.5
4
551-506
851-506
8
6
12
0.94
1.5
20
16.5
9
551-508
851-508
10
8
14
1.05
2
25
20.5
17 551-510
851-510
12
9
17
1.15
3
30
24.5
30 551-512
851-512
E-Clip
WDS 551/851
MATERIAL
-
Steel Zinc Plated or 304
Stainless Steel
DIN 6799
The clip is used with a clevis pin to secure the gas
spring to your project.
WDS No.
D
D1
L
(g)
Steel Zinc Plated
Stainless Steel
4
9.3
0.7
0.16
551-605
851-605
5
11.3
0.7
0.26
551-606
851-606
6
12.3
0.7
0.28
551-608
851-608
8
16.3
1
0.71
551-610
851-610
9
18.8
1.1
1.1
551-612
851-612
Angle Joint
WDS 551/851
MATERIAL
-
Steel Zinc Plated or 304
Stainless Steel
DIN 71802 with Safety Pin
For use on access hatches and industrial
machinery.
WDS No.
D
D1
D2
H
H1
L
S
T
(g) Steel Zinc Plated Stainless Steel
M5
8
8
19.2 10.2
22
7
10.2
15 551-705
851-705
M6
12.5
10
23.5 12.5
25
8
11.5
25 551-706
851-706
M8
16.5 13.2 29.5 16.5
30
11
14
53 551-708
851-708
M10
20
16
36
20
35
13
15.5 104 551-710
851-710
M12
16
16
36
20
35
13
15.5 221 551-712
851-712
'
'
/
&
/
+
'
'
'
/
D
H
D x T deep
D1
L
D2
S a/f
H1
ZP
304
ZP
304
ZP
304
