SECTION 14 - GAS STRUTS & END FITTINGS
WDS
WDS
www.wdsltd.co.uk14-13
&
0845 606 66 77
•
:
www.wdsltd.co.uk•
*
sales@wdsltd.co.ukA
B
D
E
L
L1
L2
S
T
Force
Range
Rod Dia Body Dia
Extended
Shoulder
Length
Stroke
Fitting
Length
Rod End
Thread
Rod End
Thread
Length
Newtons
(kg)
WDS No.
6
15
6
9
172
60
30 M6x1.0 9 20-400 0.184 850-0615060RR
6
15
6
9
252 100
30 M6x1.0 9 20-400 0.209 850-0615100RR
6
15
6
9
352 150
30 M6x1.0 9 20-400 0.239 850-0615150RR
6
15
6
9
452 200
30 M6x1.0 9 20-400 0.269 850-0615200RR
8
19
6
9
252 100
30 M6x1.0 9 50-700 0.254 850-0819100RR
8
19
6
9
352 150
30 M6x1.0 9 50-700 0.299 850-0819150RR
8
19
6
9
452 200
30 M6x1.0 9 50-700 0.339 850-0819200RR
8
19
6
9
552 250
30 M6x1.0 9 50-700 0.389 850-0819250RR
10
22
8
12
457 200
36 M8x1.25 12 100-1200 0.559 850-1022200RR
10
22
8
12
557 250
36 M8x1.25 12 100-1200 0.614 850-1022250RR
10
22
8
12
657 300
36 M8x1.25 12 100-1200 0.679 850-1022300RR
10
22
8
12
857 400
36 M8x1.25 12 100-1200 0.799 850-1022400RR
14
28
10
14
462 200
43 M10x1.5 14 200-2500 0.929 850-1428200RR
14
28
10
14
662 300
43 M10x1.5 14 200-2500 1.149 850-1428300RR
14
28
10
14
862 400
43 M10x1.5 14 200-2500 1.384 850-1428400RR
14
28
10
14 1062 500
43 M10x1.5 14 200-2500 1.604 850-1428500RR
Stainless Steel
Gas Struts with
Swivel Eye Rose
Joints
WDS 850
MATERIAL
-
Body - 316 Stainless Steel
Rod - 316 Stainless Steel
Hardened
Adjusting Valve - Brass
Adjustable Force - Supplied at
maximum force to be adjusted
in position to suit the specific
application.
See also the full range of end
fittings to suit your
application.
A
B
L1
L
L2
L2
D
D
E
E
Pressure releasing
screw in brass end
316
