SECTION 19 - TOGGLE CLAMPS & ACCESSORIES WDS
WDS
19-17 & 0845 606 66 77 • : • *
Horizontal Clamp -
Adjustable Spindle
Horizontal Clamp -
Adjustable Spindle
WDS 4025
WDS 4025
MATERIAL -
Steel, zinc plated and passivated
Flanged base. Adjustable spindle
position. Supplied with set screw,
nuts and flanged washers
Refer to 4053, 4055, 4057, 4059
for plain spindles, swivel spindles,
pads and brackets
See 4083 Series for this part in
Stainless Steel
MATERIAL -
Steel, zinc plated and passivated
Cast Iron Base. Adjustable spindle
position.
Supplied with set screw, nuts and
flanged washers
Refer to 4053, 4055, 4057, 4059 for
plain spindles, swivel spindles, pads
and brackets
See 4083 Series for this part in
Stainless Steel
B B1 B2 D D1 H H1 H2 L L1 L2 L3 L4 Arm
Opens
Max Holding
Force (kg) (kg) WDS No.
38 23 28 5.5 M6 56 28 14 167 72 38 26 6 90° 150 0.26 4025-204
38 24 - 7 M6 41 27 13 140 45 40 26 7 90° 200 0.17 4025-205
47 28 32.5 6.5 M8 70 32 17 211 90 42 26 8 90° 250 0.38 4025-206
62 41 43 8.6 M10 92 45 20 255 105 59 41 9 90° 350 0.90 4025-208
68 41 43 8.6 M12 110 57 25 305 130 63 41.3 12.7 90° 450 1.50 4025-209
B B1 D D1 H H1 H2 L L1 L2 L3 L4
Arm
Opens
Max Holding
Force (kg) (kg) WDS No.
48 30 8.4 M12 84 52 25 270 78 90 70 10 90° 700 1.15 4025-210
Horizontal Clamp -
Adjustable Spindle
WDS 4083
MATERIAL -
Stainless Steel BS 304 S15
Flanged base. Adjustable spindle
position.
Supplied with set screw, nuts and
flanged washers
See 4025 Series for this part in
steel
B B1 D D1 H H1 H2 L L1 L2 L3 L4
Arm
Opens
Max Holding
Force (kg) (kg) WDS No.
24 16 4.5 M4 22 15 7 75 24 25 16 4 85° 50 0.03 4083-201
% %
/ /
'
/ /
+ +
'
+
/
% %
/ /
'
/ /
+ +
'
+
/
/ /
'
+
+
+
/
&HQWUDO KROH IRU
DGGLWLRQDO KROG GRZQ
/
%
' /
%
/ /
'
+
+
/
&HQWUDO KROH IRU
DGGLWLRQDO KROG GRZQ
/
%
' /
%
L2 L1
H1 H2
D
H
L
L3 L4
B2 B1
D
4025-205 & 4025-206
B
4025-204, 4025-208, 4025-209
Please Note! 4025-205 has an open ended arm
4025-204 Version
ZP
ZP
304
