sales@wdsltd.co.ukDeep Pot Magnets
WDS 5741
Technical Information
• Cylindrical magnets in a mild steel pot with poles in the same plane
• Threaded hole for secure fixing
• Provides superior grip at contact
• Pot Magnets are constructed from Alinco 5 (Magnet), Aluminium Ring (Spacer) and Mild Steel (Pot)
• Pot Magnets can be used in temperatures up to 220°C
• Pot Magnets have an insulated magnetic circuit, preventing flux leakage when fitted into jigs and
fixtures
• Supplied with keeper
The magnets have a variety of uses, including:
• Gripping and lifting applications
• Positioning jigs
• Soldering fixtures
• Sinking into jigs & fixtures
• Securing and fixing
D
D1
H
T
Adhesive Force
(N)
Weight
(kg)
WDS No.
17
M6
16
4
18
26
5741-201
21
M6
19
5
28
50
5741-202
27
M6
25
6
65
110
5741-203
35
M6
30
9
115
214
5741-204
65
M12
43
13
400
1080
5741-205
D1
H
T
D
MATERIAL
-
Steel Body with AlNiCo Magnetic
Core painted red
Temperature Range - Max 450
°
C
