SECTION 19 - TOGGLE CLAMPS & ACCESSORIES
WDS
&
0845 606 66 77
•
:
www.wdsltd.co.uk•
*
sales@wdsltd.co.uk19-8
WDS
www.wdsltd.co.ukA B C D E F H H1 H2 L
Clamp
Opens
Holding Capacity
(kg)
(g)
WDS No.
12.7 27 5.4 5.1 M6 5.8 135 33.4 11 33 95°/185°
150
230
866-204
19 35 7 7.1 M8 6 190 46 17.5 53 90°/150°
250
418
866-206
Vertical Toggle
Clamp - Fixed
Spindle
WDS 866
MATERIAL
-
Body - Die-stamped steel,
zinc plated to resist corrosion.
Hand Grip - Oil resistant red
vinyl
(
+ +
/
$
%
&
'
)
+
Vertical Clamp -
Solid Arm
WDS 4005
MATERIAL
-
Steel, zinc plated and
passivated
Flanged base. Solid arm
With spindle retainer supplied loose
complete with set screw and nuts
for welding in the desired position
B B1 B2 D H H1 H2 L L1 L2 L3 S
Arms Open
Holding
Force
(kg)
(kg) WDS No.
stop
pin 1
stop
pin 2
stop
pin
removed
32 6 46 7.1 175 30 18 85 35 19 8 M8 90°
120°
160°
250 0.35 4005-201
45 8 63 8.3 215 43 20 90 50 32 9 M10 90°
120°
160°
350 0.60 4005-202
45 10 64 8.7 225 48 22 127 53 32 9 M12 90°
120°
160°
450 1.20 4005-203
70 10 95 12.3 308 82 32 159 76 51 12.7 M16 90°
120°
160°
550 2.30 4005-204
/ /
+
+
6WRS SRVLWLRQ
6WRS SRVLWLRQ
%
+
%
%
' / /
ZP
S=set screw size Steel
ZP
